MTX TH750.1

THUNDER SERIES

CLASS D MONO AMPLIFIER

750 WATTS RMS @ 1 OHM

CIRCUIT TOPOLOGY                                    Mono Class D

RMS POWER OUTPUT @ 1 OHM                    750 Watts

RMS POWER OUTPUT @ 2 OHM                    500 Watts

RMS POWER OUTPUT @ 4 OHM                    250 Watts

RMS POWER OUTPUT AT 4 OHM BRIDGED      N/A

TOTAL HARMONIC DISTORTION                     <0.1%

SIGNAL TO NOISE RATIO                             >100dB

INPUT SENSITIVITY                                     10V - 200MV

CROSSOVER RANGE                                    50 Hz - 250 Hz

FREQUENCY RESPONSE                                20 Hz - 250 Hz

BASS BOOST                                               0dB - 12dB

SUBSONIC FILTER                                       10 Hz - 55 Hz

EBC BASS KNOB                                            Yes

RECOMMENDED FUSE RATING                     80A - 100A

DIMENSIONS H X W X D                             2” x 9 3/4” x 7”
